Thermal Phase Change Material_Thermal Phase Change Materials

Thermal Phase Change Material

Products Features:

◇2.00 W/mk thermal conductivity
◇Silicone-Free Thermal Pad
◇Naturally tacky for easy applicaiton
◇Electrically insulating

Typical Applications Include:

--Network Equipement, Mass Storage devices
--Industrial Automation, Telecom Device
--Smart TV Stick, Wireless Hub,Flat Panel displays, Power supply.

Typical Properties of This Materials:

Typical Properties of TCSF200 Silicone-Free Thermal Conductive Pad
Properties	Units	TCSF200 Series	Test Method
Material	---	Acrylic	---
Color	---	Grey	Visual
Thickness	mm	0.5 to 5	---
Hardness	Shore 00	60	ASTM D2240
Density	g/cc	3.13	ASTM D792
Heat Capacity	1/g-K	1.1	ASTM E1269
Outgassing TML	---	0.12%	ASTM E595
Outgassing CVCM	---	0.06%	ASTM E595
Continuous Use Temp	℃	-60 to 200	EN344
ELECTRICAL
Dielectric Breakdown Voltage	Vac	≥200 Vac/mil	ASTM D149
Volume Impedance	ohm-cm	6.0 x10⁹	ASTM D257
Flame Rating		V 0	UL 94
THERMAL
Thermal Conductivity	W/m.k	2.0	ASTM D5470

Note: Standard Roll Form: 300mm(W) x 50m (L) or 76M (L) , Custom configuration Available

Below info will be helpful for your right application

How to transfer or dissipate the heat from the heat-generating components to heat sinks?

How To Select the Right Thermal Interface Materials for your new application?

Pls feel free to contact us as Thermal Management Solutions available in SinoGuide.
